SKU | CM-eXT2-10W-R-DE |
Enclosure - Front | Aluminum |
Enclosure - Rear | Plastic |
LCD Size | 10.1 inch Wide TFT Color |
Colors | 16.7M |
Resolution | 1280 x 800 WXGA (16:10) |
Effective Display Area (W x H) | 216.96 x 135.60 mm |
PPI | 149 |
Backlight | LED |
Luminance | 500 cd/m² |
Contrast Ratio | 800:1 |
Backlight Life | 50,000 Hours |
Touch Panel | 5 wire resistive |
Touch Panel Accuracy | Active Area Width (X) ±2%, Height (Y) ±2% |
Display Orientation | Landscape (Standard, 180°), Portrait (90°, 270°) |
Memory | 2 GB LPDDR4 |
Storage | 8 GB eMMC |
SD Card | - |
COM 1 | RS-422/485 |
COM 2 | RS-232C |
Ethernet | One 10/100/1000 port |
USB Host | One Type A |
Tool Port | One USB-C Device |
Audio | - |
Rated Voltage | 24 VDC, Class 2 |
Inrush Current | 30 A maximum |
Power Consumption | 15 W (Max: 16 W) |
Operating System | Embedded Linux |
Project Memory | 250 MB |
User Memory | 4 GB |
Realtime Clock | Realtime clock built into panel, backed up for 10 years at 25°C |
Acknowledgment Sound | Electronic buzzer |
Agency Approvals - UL | UL61010-1 / UL61010-2-201 (E231117) |
Agency Approvals - CE | Electromagnetic Compatibility Directive 2014/30/EU (EMC) |
Agency Approvals - FCC | The 47 CFR, Part2, Part15 and Part 18 Of FCC Requirement |
Agency Approvals - KC | Registration of Broadcasting and Communication Equipments |
Agency Approvals - Protection Class | Front: IP66, NEMA Type: 4X, 12 |
Operating Temperature | 0 – 65°C (32 –149°F) |
Storage Temperature | -25 – +75°C (-13 – +167°F) |
Operating Humidity | 10–90% RH (below 29℃, not condensed) |
Storage Humidity | 10–90% RH (below 39℃, not condensed) |
Dimensions | 262.3 x 187.9 x 51.9 mm (10.32 x 7.39 x 2.04 in) |
Panel Cut | 254 x 179 mm (10 x 7.04 in) |
Weight | 1.4 Kg (3.09 lbs) |
VESA (W x H) | N/A |
