| SKU | CM-iXT10CD-D |
|---|
| Display | 10.4" TFT LCD |
|---|
| Touch Panel | 4 wire resistive |
|---|
| Resolution | 800 × 600 |
|---|
| Color | 262k colors |
|---|
| Luminance | 700 cd/m² |
|---|
| Backlight Life | 50,000 hours |
|---|
| Memory | 512 MB DDR2 |
|---|
| Storage | 128 MB SLC NAND Flash |
|---|
| Operating System | Windows Embedded Compact 7 |
|---|
| Programming Tool (HMI) | XpanelDesigner |
|---|
| Audio | None |
|---|
| Ethernet | 10/100 BASE-T |
|---|
| Serial Interface (COM1) | RS-422/485 |
|---|
| Serial Interface (COM2) | RS-232C |
|---|
| Serial Interface (COM3) | RS-232C |
|---|
| USB Host | 1 Port |
|---|
| Tool Port | 1 Port |
|---|
| SD Card Slot | 1 Slot |
|---|
| Rated Voltage | 24 VDC (0.46 A) |
|---|
| Enclosure | Aluminum |
|---|
| Power Consumption | 9 W |
|---|
| Weight | 2.47 kg (5.43 lbs) |
|---|
| Operating Humidity | 10–90% RH, No condensation |
|---|
| Operating Temperature | 0 – 65ºC |
|---|
| Storage Temperature | -20 – 65ºC |
|---|
| Vibration Resistance | JIS B 3502, IEC/EN 61131-2 compliant |
|---|
| Noise Immunity | Impulse, EFT/Burst, Surge, ±2 kV, 1 μs |
|---|
| Ambient Conditions | Avoid corrosive gas and excessive dust |
|---|
| Operating Altitude | ≤ 2000 m |
|---|
| Pollution | ≤ 2 |
|---|
| Cooling | Natural air cooling |
|---|
