High-Speed Counter Expansion Module, Sourcing Input
- PLC-S High-Speed Counter (HSC) Module
- 2-Channel
- 200 kHz
- 5/12/24 VDC
- Source or Sink
- CM0-TB32M terminal block and CM0-SCB15M connection cable required
%20Module%0A2-Channel%0A200%20kHz%0A5/12/24%20VDC%0ASource%20or%20Sink%0ACM0-TB32M%20terminal%20block%20and%20CM0-SCB15M%20connection%20cable%20required%0A%0A%0A%0A%0A%0A%0A%0A%0A%0A
){kind=link}
High-Speed Counter Expansion Module, Sourcing Input
Sale price฿ 210.00
| SKU | CM3-SP02HSC |
|---|---|
| I/O Points | 16 points |
| Sensor | 2 channels |
| Count Input Signal - Phase | 1 Phase input / 2 Phase input |
| Count Input Signal - Level (фA, фB) | 5/12/24 V DC, 2–5 mA |
| Count Input Signal - Types | PNP or NPN Encoder (-Common) |
| Count - Speed | 200 kpps |
| Count - Range | 32-bit signed binary values (-2,147,483,648 to 2,147,483,647) |
| Count - Mode | Up/Down Preset Counter + Ring Counter |
| Compared - Compared Range | 32-bit signed binary values |
| Output - Comparison |
Compared value < Present value Compared value = Present value Compared value > Present value |
| External Input | 5/12/24 V DC, 2–5 mA |
| External Output | TR (SINK Type) Output, 12–24 V |
| Power Consumption | 90 mA |
